3.3.6.8 External Control Contacts – PGM 168
The MPBs include programmable contacts, which can be used to control external devices. Refer
to Table 1.1-1 System Capacity Chart for number of available contacts. Each contact is assigned
to activate under one of several conditions. As a Loud Bell Contact (LBC), the contact will activate
when the assigned station or group receives an external call. Note for LBC, when the system is in
the Night or Timed Ring mode, the contact will activate for incoming UNA calls and will ignore any
station assignment. The contact may alternatively activate as a Door open contact, when External
Page Zone 1 is accessed.
PROCEDURE:
EXT CONTROL CONTACT
PRESS FLEX KEY (1-2 )
1. Press the [PGM] button and dial 168.
EXT CONTROL CONTACT
NO 1 : . . . (1-3)
Select Flex button 1~2 for the desired External Control
contact.
Use the dial-pad to enter desired data.
1: LBC + station number
2: Door open
3: External Page 1 access
Press the [Save] button to store the External Contact data
entry.
3.3.6.9 LCD Display Mode -PGM 169
The LCD display mode sets the time (12/24 hr.), date (day/month order), language and day-of-
week display. Refer to Table 3.3.6.9-1 and Table 3.3.6.9-2 for a description of the modes, the
data entries required and LCD displays for each attribute.
PROCEDURE:
LCD DISPLAY MODE
PRESS FLEX KEY (1-4)
1. Press the [PGM] button and dial 169.
Select the desired Flex button; refer to Table 3.3.6.9-1.
Use the dial-pad to enter the desired mode and language,
refer to Table 3.3.6.9-1 and Table 3.3.6.9-2.
Press the [Save] button to store the LCD Display mode data
entry.
