4.4.5.17 SMDR Attributes - PGM 177
Selecting SMDR Attributes will display the SMDR Attributes data entry page. Click [Save] button
after changing Value.
Figure 4.4.5.17-1 SMDR Attributes
Station Message Detail Recording (SMDR), which is output over an RS 232 port or TCP channel,
contains details on both incoming and outgoing calls. Various SMDR attributes can be assigned
including; output records for all calls or LD only, call cost per pulse when using call metering, etc.
Refer to the following table for a description of each Attribute and the data entries required.
Table 4.4.5.17-1 SMDR ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Save Enable
The system can output all outgoing call records (ON) or, to
allow for PSTN call set-up times, only records for calls that
exceed the SMDR Timer (OFF). For SMDR Timer settings
refer to “Start Timer” as the below.
OFF
ON
OFF
Print Enable
The system can output SMDR records automatically as they
occur (real-time) or only when requested. When this attribute
is ON, SMDR is sent at call completion.
OFF
ON
ON
Record Type
The system can record all outgoing calls or only long distance
calls. Long distance calls are identified by the LD digit count
and LD codes assigned in “Long Distance code”.
Long Distance/
ALL calls
Long
Distance
