3.3.6.3 Alarm Attributes – PGM 163
The system can monitor an external contact. This contact is most often employed as an Alarm
indicator or Doorbell. The Alarm attributes define the operation of the external contact. The Alarm
Signal sent to assigned stations can be repeating or a single burst, the former is often desired.
For the Doorbell, a single tone is sent each time the contact activates. Refer to Table 3.3.6.3-1 for
a description of the features, the data entries required and LCD displays for each attribute.
PROCEDURE:
SYSTEM ALARM ATT
PRESS FLEX KEY (1-8)
1. Press the [PGM] button and dial 163.
Press the desired Flex button; refer to Table 3.3.6.3-1.
Use the dial-pad to enter desired data for the attribute, refer
to Table 3.3.6.3-1.
Press the [Save] button to store the data entry.
Table 3.3.6.3-1 ALARM ATTRIBUTES (PGM 163)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
ALARM ENABLE
(1:ON/0:OFF) : OFF
This parameter enables the
contact monitoring circuitry.
0: OFF
1: ON
OFF
2
ALARM CONTACT TYPE
(1:CLOSE/0:OPEN) : CLOSE
This parameter establishes the
contact state that will activate the
0: Open
1: Close
CLOSE
3
ALARM/DOORBELL MODE
(1:ALARM/0:BELL): ALARM
The contact can be treated to
function as a doorbell instead of an
alarm.
0: Bell
1: Alarm
ALARM
4
ALARM SIGNAL MODE
(1:RPT/0:ONCE) : RPT
The assigned stations will receive a
Repeating signal or single burst
0: Once
1: Repeat
RPT
5
EMER CALL NOTIFY
(1:ON/0:FF) : ON
This parameter enables/disables
the emergency call notification.
0: OFF
1: ON
ON
6
DCOB FAULT NOTIFY
(1:ON/0:FF) : ON
This parameter enables/disables
the DCOB Fault notification.
0: OFF
1: ON
ON
7
SIP REG FAULT NOTIFY
(1:ON/0:FF) : ON
This parameter enables/disables
the SIP Registration Fault
0: OFF
1: ON
ON
8
TEMP LICENSE NOTIFY
(1:ON/0:OFF) : ON
This entry enables user to get the
notification before expiring Temp
0: OFF
1: ON
ON
