iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
176
Table 3.3.9.1.3-1 LCR DIGIT MODIFICATION (PGM 222)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
7
DMT 55 NET NUM PLAN BIN
(000-251) : . . .
This entry defines the Net Number Plan
Table bin that the system will attempt to use
for the transit out call.
000~251
8
DMT 55 SMDR CODE
....
This only used for TNET with CM. This code
will be send to CM when the TNET status is
changed from Local survival mode to bypass
4 digit
3.3.9.1.4 LCR Table Initialize — PGM 223
The LCR Table Initialize allows global values to be assigned to the various Digit Modification
Table entries. In addition, the LCR Leading Digits and LCR Digit Modification Tables can be
initialized, no entries state.
PROCEDURE:
INITIALIZE LCR DB
PRESS FLEX KEY (1-6)
1. Press the [PGM] button and dial 223.
Press the Flex button (1~6) for the desired Table entry, refer
Use the dial pad to enter the desired LCR data, refer to
Table 3.3.9.1.4-1.
Press the [Save] button to store the data entry.
Table 3.3.9.1.4-1 LCR TABLE INITIALIZE (PGM 223)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
ENTER DMT INIT VAL(DAY1)
. . . . . .
This entry permits the global setting of the
Digit Modification Table Time Zone 1 to 3
indices
2
ENTER DMT INIT VAL(DAY2)
. . . . . .
This entry permits the global setting of the
Digit Modification Table Time Zone 1 to 3
indices
3
ENTER DMT INIT VAL(DAY3)
. . . . . .
This entry permits the global setting of the
Digit Modification Table Time Zone 1 to 3
indices
4
ENTER CO GRP INIT VAL
. .
This entry permits the global setting of the
CO/IP Group to be used for LCR calls.
01~21
5
ENTER ALT INDEX INIT VA
. .
This entry permits the global setting of the
Digit Modification Alternate Index.
00~99
6
INITIALIZE ALL LCR ?
Pressing [Save] will return the LCR LDT
and DMT tables to the default (no entries)
To Next Page
