iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
210
3.3.13.2 Green mode time setting – PGM 501
It is applied for SLIB, DSIB and HYIB. Regarding the exact board related to terminal, refer to
iPECS eMG Hardware Description and Installation Manual.
PROCEDURE:
GREEN MODE TIME
ENTER WEEK DAY NO (1-7)
1. Press the [PGM] button and dial 501 and enter the day
from 1 to 7 by dial pad (Ex.1).
(MON) GREEN MODE TIME
F1:ON TIME F2:OFF TIME
Press the desired Flex button 1 or 2.
Press the Flex button, 1 ~ 2, for the desired setting, refer to
Table 3.3.13.2-1.
Use the dial pad to enter the required data, refer to Table
Press the [Save] button to save any changes.
Table 3.3.13.2-1 GREEN MODE TIME (PGM 501)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
POWER ON TIME (HH:MM)
NOT ASSIGNED
Enable power on time Not assigned
2
POWER OFFIME (HH:MM)
NOT ASSIGNED
Enable power off time Not assigned
