iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
95
3.3.5.10 T1 Line Timers – PGM 152
North American T1 standards require that the T1 terminating device, in this case the iPECS eMG,
include various “adjustable” timers and counters as described below.
PROCEDURE:
COL T1 ATT
ENTER CO RANGE
1. Press the [PGM] button and dial 152.
01-02 COL T1 ATT
PRESS FLEX KEY (01-13)
Use the dial-pad to enter a CO Line range (Ex. 01-02). For a
single CO Line, enter the same number twice.
Press the desired Flex button; refer to Table 3.3.5.10-1.
Use the dial-pad to enter desired data for the Attribute, refer
Press the
button to store the data entry.
Table 3.3.5.10-1 T1 LINE TIMERS (PGM 152)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
01-02 PAUSE
(1-9) : 2 (sec)
A timed pause may be included in a
Speed Dial number, in which case,
the pause time is defined by this
entry.
Not currently implemented.
1~9 (seconds) 2
2
01-02 RLS GRD
(01-60) : 20 (100ms)
The release guard timer defines the
length of time the system will
maintain a Line as busy after the
call has been terminated to assure
the PSTN has sufficient time to
‘clear down’ the circuit. Not
currently implemented.
01~60
(100 ms)
20
3
01-02 DT DELAY
(02-50) : 10 (100ms)
The DT (Dial tone) Delay timer
defines the duration that dial tone
must be received for DT
recognition.
Not currently implemented.
02~50
(100 ms)
10
4
01-02 INTER DGT
(15-30) : 15 (20ms)
The Inter Digit timer defines the
duration between digit
transmissions.
Not currently implemented.
15~30
(20 ms)
15
5
01-02 WINK
(07-15) : 10 (20ms)
For TIE or DID Lines the Wink timer
defines the length of time the ‘wink’
(T1 TIE line circuit reversal) will last.
7~15
(20 ms)
10
