Table 3.3.5.10-1 T1 LINE TIMERS (PGM 152)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
6
01-02 OP RATE ( 0- 3)
60-40 (10pps) (0)
For Pulse signaling, defines the
duration and make/break ratio of
each pulse.
0: 60-40
(10pps)
1: 66-33
(10pps)
2: 60-40
(20pps)
3: 66-33
(20pps)
60-40
(10pps)
7
01-02 SEZ DTC
(000-127) : 003 (20ms)
This timer defines the length of a
valid ‘line seizure’ signal.
0~127
(20 ms)
3
8
01-02 RELEASE
(000-127) : 007 (20ms)
For Ground Start Lines, defines the
minimum length of time ground will
not be applied to the TIP side from
the PSTN.
0~127
(20 ms)
7
9
01-02 IASG TY
(1:DTMF/0:PULSE) : DTMF
Incoming Address Signaling Type
defines the type of signaling (DTMF
or Pulse) expected.
0~1 DTMF
10
01-02 RING DTC
(2-9) : 2 (100ms)
The Ring DTC (detect) timer
defines the minimum acceptable
length of the Ring-on time during a
ring cycle.
2~9
(100 ms)
2
11
01-02 RING STOP
(10-60) : 60 (100ms)
The Ring Stop timer defines the
maximum Ring-off time during a
ring cycle.
10~60
(100 ms)
60
12
01-02 COLLECT DGT
(1-6) : 3
Collect DGT (digits) defines the
number of digits expected on a DID
line.
1~6 3
13
01-02 STORE TIME
(01~15) : 15 (1sec)
For DID lines, this timer defines the
maximum delay between incoming
DID digits.
1~15
(second)
15
