iPECS UCP - Station Group Attributes - PGM 191

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
147
3.3.7.2 Station Group Attributes – PGM 191
Each type of group has a different set of available attributes relating to announcements, timers,
overflow, etc. Table 3.3.7.2-1 through Table 3.3.7.2-8 provides descriptions for the attributes,
LCD displays and data entries required. The attributes for the Circular and Terminal Hunt groups
are given in Table 3.3.7.2-1 and the UCD attributes include the ACD functions Table 3.3.7.2-2. In
addition, there are no attributes for a group assigned as a Net VM group in PGM 190.
PROCEDURE:
STATION GRP ATT
ENTER GRP NO(401-440)
1. Press the [PGM] button and dial 191.
CIRC GRP 401
PRESS FLEX KEY (01-21)
Use the dial pad to enter the desired Station Group. The
system will display the type of group from the Station Group
Assignment PGM 190 data (Ex. 01 Circular).
Press the Flex button for the desired attribute; refer to Table
3.3.7.2-1 to Table 3.3.7.2-8.
Use the dial pad to enter the desired Group Attributes data,
refer to Table 3.3.7.2-1 to Table 3.3.7.2-8.
Press the
[Save]
button to store the data entry.
Table 3.3.7.2-1 STATION GROUP ATTRIBUTES — CIRCULAR & TERMINAL GROUPS
(PGM 191)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
CIRC 401 ANNC 1 TMR(1s)
(000 - 999) : 015
If all stations in the group are busy
when a call is offered, the call may
continue to wait (queue) for an
available station.
If the queue period exceeds 1
st
Announcement Timer, the call may
be sent to a VSF announcement.
If the timer is set to 000, the call will
receive the first announcement, in
full, prior to the hunt process
(guaranteed announcement).
000~999
(seconds)
015
2
CIRC 401 ANNC 2 TMR(1s)
(000 - 999) : 000
After the 1
st
announcement, the 2
nd
ANNC TMR is activated. At
expiration, if the call remains
queued to the group, the call is
sent to the assigned 2
nd
VSF
announcement.
000~999
(seconds)
000
