iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
24
PROCEDURE:
Press Flex 1~6 to select the Sub-menu item desired. See
Table 3.3.2.2-1.
Button 1: IP address
Button 2: MAC address
Button 3: ARP
Button 4: REGISTRATION
Button 5: CPU Type
Button 6: Device (Board) ID
Use the dial-pad to enter desired data. For IP and MAC
addresses, an “*” is used to enter a dot (“.”)
Press the [Save] button to store the data entry.
Table 3.3.2.2-1 DEVICE & STATION ADDRESS PLAN (PGM 103)
BTN DISPLAY FEATURE DEFAULT
1
001-001 :B40EDCBF5606
VOIP 1 :10 .10 .10 .2
LCD shows:
Line 1 Sequence Number, 2 or 3 digits MAC
Address, 12 digits
Line 2 Module Type, 4 characters First Logical
port number IP Address, 7~12 digits
CO & VoIP
board IP
address set
sequentially,
from the range
in PGM 102.
1–1
SET IP ADDRESS
VOIP 1 : 10.10.10.2
Use Flex button 1 to set the device‘s IP address
in IP v4 format.
10.10.10.10~254
1–2
SET MAC ADDRESS
001-001 : B40EDCBF5606
Use Flex button 2 to enter the device‘s MAC
address in the system memory.
None
1–3
ARP
(1:ON/0:OFF): OFF
Use Flex button 3 to enable/disable Direct Send
mode, which employs layer 2 switching to local
devices.
OFF
1–4
REGISTRATION
(0:UCAST/1:MCAST): MCAST
Use Flex button 4 to enable/disable Local
Device Mode, which defines the device as on a
common LAN with the MPB.
MCAST
1–5
CPU TYPE
MSC1K
Flex button 5 displays the type of CPU
employed in the device.
1–6
DEVICE(BOARD) ID
PRIB
Flex button 6 displays the Board type
designation.
2
001-001 : B40EDCBF5606
KTU 100 :10.10.10.10
LCD shows:
Line 1 Sequence Number, 3 digits MAC
Address, 12 digits
Line 2 Station Type, 3 characters Station
Number, 2~4 digits IP Address, 7~12 digits
Station IP
address set
sequentially,
from the range
in PGM 102.
2–1
SET IP ADDRESS
KTU 100 :10.10.10.10
Use Flex button 1 to set the device‘s IP address
in IP v4 format.
10.10.10.10~254
