iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
202
Table 3.3.11.2-1 TNET CM ATTRIBUTES (PGM 331)
8
CM TOTAL PORT
(000 – 999) : 011
This field defines the total number of
ports the LM will request be allocated
by the CM for devices attached to the
LM.
This value must be equal to or less than
the port count in the CM for the LM
000-999 000
9
POLLING COUNT
(00 – 99) : 05
This field defines the maximum polling
failures an LM considers a WAN fault.
00-99 05
10
POLLING INTERVAL
(00 – 99) : 02
This field defines the interval time
between LM to CM polling attempts.
00-99 02
3.3.11.3 TNET LM ATTRIBUTES – PGM 332
The CM (Central MPB/MPB) must be programmed with the MAC and IP address of each LM
(Local MPB) in the Centralized Control network as well as the maximum configuration of each LM.
The port counts define the ports, which are allocated in the CM database for use by devices
registered to the LM. The number of ports defined in the database of each LM, sees PGM 331,
must be equal to or less than the ports defined in the CM for the LM, in order to register properly.
VoIP channels are needed to support RTP Packet relay or codec translation between other
devices. The CO port count must include any VoIP channels required.
PROCEDURE:
TNET LM ATTRIBUTES
ENTER BIN NO(01-15)
1. Press the [PGM] button and dial 332.
TNET LM(01) ATTRIBUTES
PRESS FLEX KEY (1- 4)
Use the dial pad to enter the bin number associated with the
LM.
Press the Flex button, 1~4 for the desired setting, refer to
Use the dial-pad to enter the required data, refer to Table
3.3.11.3-1.
Press the [Save] button to store the new data.
Table 3.3.11.3-1 TNET LM ATTRIBUTES (PGM 332)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
LM(01) MAC ADDRESS
0000000000000
This field defines the MAC address of the
LM that will be part of the TNET
environment and is used by the CM for
MAC
address
