3.3.11.7 TNET LM Alarm Attributes – PGM 336
The LM incorporates circuitry to monitor an external contact. This contact is most often employed
as an Alarm indicator or Doorbell. The Alarm attributes define the operation of the monitoring
circuitry. For the Alarm, the signal to the LM stations can be repeating or a single burst, the
former is often desired. For the Doorbell, a single tone is sent each time the contact activates.
PROCEDURE:
TNET LM ALARM ATTR
ENTER BIN NO (01-15)
1. Press the [PGM] button and dial 336.
LM(01) ALARM ATTR
PRESS FLEX KEY (1-4)
Select LM number
Press the desired Flex button; refer to Table 3.3.11.7-1.
Use the dial-pad to enter desired data for the attribute, refer
to Table 3.3.11.7-1.
Press the [Save] button to store the data entry.
Table 3.3.11.7-1 ALARM ATTRIBUTES (PGM 336)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
ALARM ENABLE
(1:ON/0:OFF) : OFF
This parameter enables the external
contact monitoring circuitry.
0: OFF
1: ON
OFF
2
ALARM CONTACT TYPE
(1:CLOSE/0:OPEN) : CLOSE
This parameter establishes the
contact state that will activate the
Alarm, close or open.
0: Open
1: Close
CLOSE
3
ALARM/DOORBELL MODE
(1:ALARM/0:BELL): ALARM
The contact can be treated to
function as a doorbell instead of an
alarm.
0: Bell
1: Alarm
ALARM
4
ALARM SIGNAL MODE
(1:RPT/0:ONCE) : RPT
The assigned stations will receive a
Repeating signal or single burst
(ONCE) of alarm tone.
0: Once
1: Repeat
RPT
