iPECS UCP - PPP Attributes for UCP

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
437
4.4.7.6 PPP Attributes for UCP - PGM 205
Selecting PPP Attributes will display the PPP Attributes data entry page. Use the check boxes to
indicate which attributes to define; data for checked attributes is stored for the entire range of
stations when saved. Click [Save] button after changing Value.
Figure 4.4.7.6-1 PPP Attributes
In addition to remote access via an IP network connection, the system database may be
accessed remotely via an ISDN connection. Placing a call over an ISDN Line to the designated
PPP Station will provide a connection to the system database. The system will request a user id
and password, which must match one of the User Ids and passwords assigned. After a matching
ID and password are received, iPECS Login Home page is provided.
Table 4.4.7.6-1 PPP ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
PPP Destination
If the incoming capability is 64 Kbps unrestricted digital and
the called party number matches the PPP destination, the
system will automatically answer the call and request PPP
ID and password.
Station number None
User ID 1
The System accepts this PPP ID 1 as valid.
Max. 12 characters
likppp01
User Password 1
The password entered is used to authorize PPP ID 1.
Max. 12 characters
Ipkts01
User ID 2 The System accepts this PPP ID 2 as valid. Max. 12 characters likppp02
User Password 2 The password entered is used to authorize PPP ID 2. Max. 12 characters Ipkts02
PPP Server IP
Addr
When configured, the PPP Server IP Address must match
this entry. To apply this option the system must be restarted.
IP Address
PPP Client IP Addr
When configured, the PPP Client IP Address must match
this entry. To apply this option the system must be restarted.
IP Address
