iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
446
Table 4.4.8.1-1 SIP Common Attributes
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Port
Alarm Server
Check Usage
If IPECS doesn’t receive reply for this option 3
consecutive times, will not send Message and
Information to Alarm server. PGM 210 check message
send timer.
OFF/
ON
OFF
Terminal State
Announcement
Information (Terminal state) is sent to Alarm server if this
value is ON, not sent to Alarm server if this value is OFF.
OFF/
ON
OFF
600BE Channels
for Alarm
The number of 600BE channels reserved for Alarm SMS. 0~1 0
4.4.8.2 SIP Trunk Status Overview
Selecting SIP Trunk Status Overview displays the overview page. The page displays the Proxy,
Domain, etc. for the SIP Trunks configured in PGM 133.
Figure 4.4.8.2-1 SIP trunk status overview
