3.3.6.27 Personal Group Attribute – PGM 261
In PGM 261, Personal group attribute can be set.
PROCEDURE:
PERSONAL ATTRIBUTE
ENTER GRP NUM (01–70)
1. Press the [PGM] button and dial 261.
And Enter Group number.(eMG80:1~70 /eMG800:1~600)
PERSONAL GRP 01
PRESS FLEX KEY (1-3)
2. Press the Flex button 1~4 for the desired setting, refer to
Table 3.3.6.27-1.
Use the dial-pad to enter the desired data, refer to Table
3.3.6.27-1.
Press the [Save] button to store the data entry.
Table 3.3.6.27-1 PERSONAL GROUP ATTRIBUTES (PGM 261)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
01 USE MASTER WAKEUP
(1:ON/0:OFF) : OFF
If this value is set to ON, all
member wake-up follow by master
wake up.
If this value is set to OFF, individual
wake-up is worked by each station.
0: OFF
1: ON
OFF
2
01 USE MASTER DND
(1:ON/0:OFF) : OFF
If this value is set to ON, DND
setting affect to Master and all
member.
If this value is set to OFF, individual
DND is worked by each station.
0: OFF
1: ON
OFF
3
01 SET LINKED PAIR
(1:ON/0:OFF) : OFF
If this value is set to ON, Master
and Member Stations are linked
and only one station can be
activated.
0: OFF
1: ON
OFF
