3.3.10.3 Network CO LINE Attribute – PGM 322
PROCEDURE:
NET COL ATTRIBUTE
ENTER CO RANGE
1. Press the [PGM] button and dial 322 and enter CO range
(Ex. 0101).(eMG80 : 1-74 / eMG800: 1-600)
01-01 NET COL PGM
PRESS FLEX KEY (1-2)
Use the dial-pad to enter the CO Range.
Press the Flex button 1~2 for the desired setting, refer to
Table 3.3.10.3-1.
Use the dial-pad to enter the required data, refer to Table
3.3.10.3-1.
Press the
[Save]
button to store the new data.
Table 3.3.10.3-1 NETWORK BASIC ATTRIBUTE (PGM 322)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
01-01 NET CO GRP
( 00 – 24 ) : 00
Networking CO group programming
for Networking call.
00-24 00
2
01-01 NET CO TYPE
(0:PSTN/1:NET) : PSTN
Select network CO Line Type 0: PSTN
1: NET
PSTN
