iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
203
Table 3.3.11.3-1 TNET LM ATTRIBUTES (PGM 332)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
2
LM(01) IP ADDRESS
0 .0 .0 .0
This field displays the IP address of the
LM.
IPv4
address
3
LM(01) IPKTS PORT
(0001 - 9999) :5588
In the TNET environment, the IP KTS
protocol signaling UDP port is defined. At
present this field is not used, do not
0000-9999 5588
4
LM (01) TOTAL PORT
(000 – 999) : 000
This field defines the total number of ports
the LM will request be allocated by the CM
for devices attached to the LM.
This value must be equal to or more than
the available port count in the LM.
000-999 000
5
LM (01) MULTICAST IP
239.20.19.1
This field defines the multicast IP address
that could be used in TNET branch site.
IPv4
address
3.3.11.4 FoPSTN Attributes – PGM 333
The Fail-over function allows the systems in a Centralized Control network (TNET) environment
to complete calls from system to system over a PSTN (analog or digital) line should the WAN
connection to the CM fail. A CO Gateway/Board must be registered to the LM for local control and
access CO services. Users may call others in the normal manner and the call is routed over CO
facilities to the remote CM. When calls are directed to a DID line at the receiving system, the
system will select a line from the assigned CO Group and dial the Tel Number with the station
number dialed as the trailing digits.
PROCEDURE:
FoPSTN ATTRIBUTES
PRESS FLEX KEY (1–3)
1. Press the [PGM] button and dial 333.
Press the Flex button 1~3 for the desired setting, refer to
Table 3.3.11.4-1.
For Flex button 1 enable or disable FO. For Flex button 2,
press the [Save] button to reset the FO table. For Flex
button 3, dial the table bin number to input data.
For Flex button 3, use the dial-pad to enter the required
data, refer to Table 3.3.11.4-1.
Press the [Save] button to store the new data.
Table 3.3.11.4-1 FAIL-OVER ATTRIBUTES (PGM 333)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
ENABLE FoPSTN
(1:ON/0:OFF) : ON
This field is used to enable or disable
Fail-over operation from the CM or LM.
0: OFF
1: ON
OFF
