3.3.9.15 Digit Conversion Tables – PGM 270
The Digit Conversion Table index is assigned to the Station and CO line. And the digit conversion
can be applied according to the Apply Time Type (Unconditional, Day/Night/Timed or LCR
Day/Time) differently.
Each Table includes 200 entries of up to 16 digits; entries in the Tables can be any digit (01–15),
or “*”, “#”. Each Index can be applied by Apply Option. (All/Station/CO line/Disable)
PROCEDURE:
DIGIT CONVERSION TABLE
ENTER TABLE NO (01–15)
1. Press the [PGM] button and dial 270 and enter the table
number (Ex. 01).(eMG80 : 1-15 / eMG800:1-32)
01 DIGIT CONVERSION
ENTER BIN NO (001–200)
2. Dial Digit Conversion Table Number (01–15) and enter
the bin umber (Ex.001).
01/001 DIGIT CONV.
PRESS FLEX KEY (01–18)
3. Dial conversion Bin No (001–200).
− Flex 1: Apply Time Type
− Flex 2: Dialed Digit
− Flex 3: Unconditional Changed Digit
− Flex 4−6: Day/Night Timed Changed Digit
− Flex 7−15: LCR Time (Day/Time Zone Changed Digit)
− Flex 16 : Ring mode table
− Flex 17 : Apply Option
− Flex 18: ARS CO Access CO
4. Use the dial–pad to enter the dialed number.
5. Press the [Save] button to store the data entry.
Table 3.3.9.15-1 DIGIT CONVERSION TABLE ATTRIBUTES (PGM 270)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
01/001 APPLY T–TYPE
(0–2): UNCONDITIONAL
The Apply time type to be applied
when the dialed digit is dialed.
0: Unconditional
1: Follow DNT
2: Follow LCR
Unconditional
2
01/001 DIALED DIGIT
…………………..
The dialed digits Max. 24 digits
3
01/001 UNCOND CHANGED
…………………..
The dialed digits are converted to this
digit stream unconditionally.
Max. 24 digits
4
01/001 DAY CHANGED
…………………..
The dialed digits are converted to this
digit stream when Apply Time type is
‘FOLLOW DNT’ and current ring mode
is DAY.
Max. 24 digits
5
01/001 NIGHT CHANGED
…………………..
The dialed digits are converted to this
digit stream when Apply Time type is
‘FOLLOW DNT’ and current ring mode
is NIGHT.
Max. 24 digits
6
01/001 TIMED CHANGED
…………………..
The dialed digits are converted to this
digit stream when Apply Time type is
‘FOLLOW DNT’ and current ring mode
is TIMED.
Max. 24 digits
