iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
116
3.3.6.7 DID/DISA Destination – PGM 167
When a DID line or DISA user dials an invalid/vacant or busy station number the caller will be
sent to the assigned destination that is selected according to the CO tenancy group of the
DID/DISA line.
The destination is separately defined for invalid, busy, no answer and DND conditions and can be
defined as the Attendant, busy tone, Station Group or VSF System Announcement.
Note that for calls on a DID line to a busy station, Call Wait can be assigned, refer to PGM 113,
Station Attributes III, button 9.
Also, for DID calls only, announcements (prompts) can be sent from the VSF to the caller for
various conditions, busy, error, DND, No Answer, reroute busy, reroute error, reroute no answer,
or Attendant Transfer.
PROCEDURE:
DID/DISA DESTINATION
ENTER ICM GROUP (00-15)
1. Press the [PGM] button and dial 167.
Select ICM tenancy group (eMG80:0~15 / eMG800:0~32)
DID/DISA DESTINATION :0
PRESS FLEX KEY (1-9)
Press the [PGM] button and dial 167 and press Flexible
button (Ex.1).
BUSY DESTINATION
TONE (F1-F4)
Select the desired Flex button,
Button 1: Busy Destination (F1-F4)
Button 2: Error Destination (F1-F4)
Button 3: No Answer Destination (F1-F4)
Button 4: VSF Prompt Usage (F1-F5)
Button 5: Reroute Busy Destination (F1-F3)
Button 6: Reroute Error Destination (F1-F3)
Button 7: Reroute No answer Destination (F1-F3)
Button 8: DND destination (F1-F3)
Button 9: Reroute NET CO BUSY Destination (F1-F3)
For Flex button 1~3 or 1~4, use the dial-pad to enter 1:
ON or 0: OFF for the following VSF prompts.
1: Tone
2: Attendant
3: Station Group number
4: VSF Announcement
For Flex button 4, select Flex button 1~5 for the desired
VSF prompt and use the dial-pad to enter 1: ON or 0:
OFF:
Button 1: Busy Prompt
Button 2: Error Prompt
Button 3: DND Prompt
Button 4: No Answer Prompt
Button 5: Attendant Transfer Prompt
Press the
button to store the destination data entry.
