4.4.5.3 Alarm Attributes - PGM 163
Selecting Alarm Attributes will display the Alarm Attributes data entry page. Click [Save] button
after changing Value.
Figure 4.4.5.3-1 Alarm Attributes
The system can monitor an external contact. This contact is most often employed as an Alarm
indicator or Doorbell. The Alarm attributes define the operation of the external contact. For the
Alarm, the signal to assigned stations can be repeating or a single burst, the former is often
desired. For the Doorbell, a single tone is sent each time the contact activates. Refer to Table
4.4.5.3-1 for a description of the features and the data entries required for each attribute.
If the related alarm attributes are set to ‘Alarm & Email’ or ‘Email Noti only’, the system sends an
email to the address that set in PGM 160~161 Alarm Attributes ‘Alarm Receiver E-Mail Address
(To) & Notification Receiver E-Mail Address (To)’.
Table 4.4.5.3-1 ALARM ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Alarm Enable
This entry enables/disables the contact monitoring
circuitry.
OFF
ON
OFF
Alarm Contact Type
This parameter establishes the contact state that will
activate the Alarm, close or open.
Close/
Open
Close
Alarm Mode
The contact can be treated to function as a doorbell or an
alarm.
Alarm/
Door-Bell
Alarm
Alarm Signal Mode
The assigned stations will receive a Repeating signal or
single burst (Once) of alarm tone.
Repeat/
Once
Repeat
