3. STATION ADMIN PROGRAMMING
FOR E
MG
3.1 General
3.1.1 LCD & Button Functions
While in the Program mode, the Liquid Crystal Display (LCD) and Flex button LEDs of an Admin
Station are used to guide and indicate status of the feature. The dial-pad is most often used to
enter data after selecting a data item using the Flex buttons. In some cases, pressing a Flex
button will toggle the entry with the Flex button LED indicating the status (On/Off).
For Programs with multiple Flex button selections, the volume controls ([VOL UP] and [VOL
DOWN] buttons) may be used to select the next or previous item. The [SPEED] button is
generally employed as a delete button to erase existing entries. However, where noted, it may be
used to confirm a range input. Pressing the [CONF] button, returns to the 1
st
step of the data
entry procedure for the Program without storing unsaved entries.
The [Save] button is used to store data after entry. If there are no conflicts in the entered data,
confirmation tone will be received and the data stored. If a conflict exists, error tone is provided
and newly entered data are not saved. Generally, corrected data may be entered and stored
without restarting the entry procedure from the 1
st step.
3.1.2 Alphanumeric Data Entries
In some cases, an alphanumeric entry is required. Two (2) dial-pad digits represent each
character of an alphanumeric entry, as shown in Table 3.1.2–1 below. Use the Table to
determine the two digits that must be entered from the dial-pad for each character.
Table 3.1.2-1 ALPHANUMERIC DIAL-PAD ENTRIES
1
Q – 11
Z – 12
. – 13
1 – 10
2
A - 21
B - 22
C - 23
2 - 20
3
D - 31
E - 32
F - 33
3 - 30
4
G – 41
H - 42
I - 43
4 - 40
5
J - 51
K - 52
L - 53
5 - 50
6
M - 61
N - 62
O - 63
6 - 60
7
P - 71
R - 72
S - 73
Q - 7*
7 - 70
8
T - 81
U - 82
V - 83
8 - 80
9
W - 91
X - 92
Y - 93
Z - 9#
9 - 90
*
Blank - *1
: - *2
, - *3
0
0-00
#
#
