3.3.4.3 Board Base Attributes – PGM 132
Appliances (Boards and IP Phones) can be connected to the iPECS over a managed WAN
without the need to employ a VoIP channel. In this case, the system does not implement security
(IPSec) or QoS treatment over the link. To implement the managed WAN connectivity, the iPECS
must be assigned with the IP address of the router for all appliances that may attempt a point-to-
point connection over the managed WAN, including devices on the iPECS LAN. Note that if the
device’s Router IP address is not defined, the system will use the Router IP address defined in
PGM 102.
The default codec employed by each device can be specifically defined as G.711, G.723, G.729,
G.722 or the system default codec PGM 161 can be defined.
Note that the Sequence Number can be determined in PGM 103, Button 1.
PROCEDURE:
BOARD BASE ATTRIBUTE
ENTER RANGE (001–300 )
1. Press the [PGM] button and dial 132 and enter Range
(Ex. 001~002). eMG800 range is 0001-2890.
001-002 BOARD ATTRIBUTE
PRESS FLEX KEY (01–13)
Use the dial pad to enter the Sequence Number range of the
desired module. Use PGM 103 to determine Sequence
Press the desired Flex button; refer to Table 3.3.4.3-1.
Use the dial pad to enter the desired data, refer to Table
Press the
button to store the Table data entry.
Table 3.3.4.3-1 BOARD ATTRIBUTES (PGM 132)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
001-002 ROUTER IP ADDR
0 .0 .0 .0
Enter the default Router IP address
associated with the selected
0.0.0.0
2
001-002 DEV CODEC TYPE
(0-4): SYSTEM CODEC
Select the CODEC type for the
selected devices:
0: G.711,
1: G.723.1,
2: G.729,
3: G.722
4: System Codec refer to
0-4 4
3
001-002 FIRWALL IP ADDR
0 .0 .0 .0
Enter the Firewall IP address
associated with the selected
0.0.0.0
4
001-002 RTP SECURITY
(1:ON/0:OFF) : ON
Remote iPECS IP & LDP phones
use IPSec to assure a secure
connection. To reduce bandwidth
use, IPSec may be disabled.
0: OFF
1: ON
ON
