4.4.7.4 ICLID Route Table - PGM 203
Selecting ICLID Route Table will display the ICLID Route Table data entry page. Click [Save]
button after changing field.
Figure 4.4.7.4-1 ICLID Route Table
The system can employ ICLID (Incoming Calling Line Id) to determine the routing of incoming
external calls. Each CO/IP Line, including DID Lines and ACD group calls may be assigned to
employ ICLID routing. The system will compare the received ICLID to entries in the ICLID Route
Table and, if a match is found, will route the call to the destination defined in the ICLID Ring
Assignment Table index assigned here.
Table 4.4.7.4-1 ICLID ROUTE TABLE ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
ICLID Ring Assign Index
Index to the ICLID Ring Assignment Table that
determines the call routing.
eMG: 001~250
UCP: 001~500
None
Caller Telephone
Number
ICLID (Incoming Caller Id) to match for the index. If the
Caller Id matches the Table entry, the index is used to
select the route.
24 Digits None
Caller Name
ICLID name that is sent by the system to the
destination for the ICLID routed call.
12 characters None
Ring Tone
If the received Caller Id matches the Caller Telephone
Number, the Ring tone selected here is employed for
the call alerting.
01 ~ 16 Ring Tone
