iPECS UCP - CO Device Sequence Number -PGM 104

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
27
Table 3.3.2.2-1 DEVICE & STATION ADDRESS PLAN (PGM 103)
BTN DISPLAY FEATURE DEFAULT
7–2
SET MAC ADDRESS
001-003 : 00405A142C67
Use Flex button 2 to enter the device‘s MAC
address into system memory.
None
7–3
ARP
(0:ON/1:OFF): OFF
Use Flex button 3 to enable/disable ARP, ARP
OFF enables Direct Send, which employs layer
2 switching to local devices.
OFF
7–4
REGISTRATION
(0:UCAST/1:MCAST):MCAST
Use Flex button 4 to disable/enable Local
Device Mode, which defines the device as on a
common LAN with the system. MCAST enables
Local Device Mode.
MCAST
7–5
CPU TYPE
MS828
Flex button 5 displays the type of CPU
employed in the device.
7–6
DEVICE(BOARD) ID
WTIB
Flex button 6 displays the type designation,
WTIB.
3.3.2.3 CO Device Sequence Number -PGM 104
The system uses the Sequence Number to assign logical (software) port numbers. This
Sequence Number relates the hardware and software port numbers for each device.
PROCEDURE:
001 002 003 004 005 006
009 007 008 013 014 . . .
1. Press the [PGM] button and dial 104.
001 002 003 004 005 006
009 007 008 013 014 . . .
Press the Flex button (1~6) for the desired Sequence
Number, use the [VOL UP] and [VOL DOWN] buttons for
the next/previous set of six Sequence Numbers.
001 002 003 004 005 006
009 007 008 013 014 . . .
Using the dial pad, enter new slot numbers. Note slot
numbers cannot be duplicated and duplicates will cause an
error. The [SPEED] button may be used to erase the slot
number associated with the selected Sequence Number.
Press the
[Save]
button to store the new Slot data.
