iPECS UCP - Numbering Plans

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
631
Table C-2 Numbering Plans
BTN SUB-MENU DEFAULT REMARK
device regardless of the 3
rd
dip switch
12 First End Mac Address
00:00:00:00:00:00 First : End MAC Address to register a
device regardless of the 3
rd
dip switch
13 Second Start Mac Address
00:00:00:00:00:00 Second : Start MAC Address to register
a device regardless of the 3
rd
dip switch
14 Second End Mac Address
00:00:00:00:00:00
Second : End MAC Address to register
a device regardless of the 3
rd
dip switch
15 System IP Address plan Reset
Returns System IP Address Plan to
default values.
16
Unused
0.0.0.0
17
Unused
0.0.0.0
18
MPB DNS IP Address
0.0.0.0
19
MPB DHCP
OFF
PGM: 103 Device IP Address Plan
1 CO/IP Device IP Address
10.10.10.10~254
-
OFF
MCAST
Flex 1: Set IP Address
Flex 2: Set Mac Address
Flex 3: ARP
Flex 4: Registration
Flex 5: CPU Type
Flex 6: Device ID (type)
2 Station IP Address
10.10.10.10~254
-
OFF
MCAST
Flex 1: Set IP Address
Flex 2: Set Mac Address
Flex 3: ARP
Flex 4: Registration
Flex 5: CPU Type
Flex 6: Device ID (type)
3 MISU IP Address
10.10.10.10~254
-
OFF
MCAST
Flex 1: Set IP Address
Flex 2: Set Mac Address
Flex 3: ARP
Flex 4: Registration
Flex 5: CPU Type
Flex 6: Device ID (type)
4 VMIB & VSF IP Address
10.10.10.10~254
-
On
On
Flex 1: Set IP Address
Flex 2: Set Mac Address
Flex 3: ARP
Flex 4: Registration
Flex 5: CPU Type
Flex 6: Device ID (type)
5 MCIB_V IP Address
10.10.10.10~254
-
OFF
MCAST
Flex 1: Set IP Address
Flex 2: Set Mac Address
Flex 3: ARP
Flex 4: Registration
Flex 5: CPU Type
Flex 6: Device ID (type)
6
Device IP Address Plan
System Reset
7 WITB IP Address
10.10.10.10~254
-
OFF
MCAST
Flex 1: Set IP Address
Flex 2: Set Mac Address
Flex 3: ARP
Flex 4: Registration
