iPECS UCP - NA ISDN Line Attributes - PGM 150

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
91
Table 3.3.5.7-1 CO Additional Attributes (PGM 148)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
10
01-02 CC ANS TMR
(001-250): 010 (100ms)
If it is set to Double Answer
for collect call blocking, this
timer is sending dummy
answer signal.
1-250 (100ms) 10
11
01-02 CC IDLE TMR
(001-250): 020 (100ms)
If it is set to Double Answer
for collect call blocking, this
timer is sending dummy idle
signal.
1-250 (100ms) 20
12
01-02 LINE MONITORING
(1: ON / 0: OFF): ON
This determines that detect
line fault or not.
0: OFF
1: ON
ON
13
01-02 RING DETECT REG
(000-255) : 015
In the web admin, it is
located in the Maintenance
page [Appliances Control] >
[Analog CO Param Set].
000-255 015
3.3.5.8 NA ISDN Line Attributes – PGM 150
To comply with the North American ISDN standards, certain attributes must be defined for the
system. These include Directory (telephone) Number and Service Profile (SPID) for the device.
Note that this programming is required only for “Country Code” 1, USA installations.
PROCEDURE:
COL NA ISDN ATT
ENTER CO RANGE
1. Press the [PGM] button and dial 150.
01-02 COL NA ISDN ATT
PRESS FLEX KEY (1-8)
Use the dial-pad to enter a CO Line range. For a single CO
Line, enter the same number twice.
Press the desired Flex button; refer to Table 3.3.5.8-1.
Use the dial-pad to enter desired data for the Attribute, refer
to Table 3.3.5.8-1.
Press the [Save] button to store the data entry.
Table 3.3.5.8-1 NA ISDN ATTRIBUTES (PGM 150)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
01-02 TYPE OF PX(1-4)
NI1 (1)
The type of PSTN determines several
specifics of the protocol
and is required
for proper operation.
1: NI 1
2: NI 2
3: 5 ESS
4: NORTEL
NI 1
