iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
356
4.4.5.5 Multi-cast IP/Port - PGM 165
Selecting Multi-cast IP/Port will display the Multi-cast IP/Port data entry page. Click [Save] button
after changing Value.
Figure 4.4.5.5-1 Multi-cast IP/Port
Multi-cast is employed by the system to send BGM, MOH, paging and Push-To-Talk packets.
Employing a single multi-cast packet reduces the overall LAN traffic. In some cases, specifically
when multiple systems are connected to the same default gateway (router) it may be
advantageous to define different IP ports for each system.
Table 4.4.5.5-1 eMG80 MULTI-CAST IP/Port
ATTRIBUTE DESCRIPTION RANGE DEFAULT
BGM Internal RTP and RTCP ports for internal BGM. 0000-9999 8100
(8101)
BGM External 1 RTP and RTCP ports for external BGM 1. 0000-9999 8102
(8103)
BGM External 2 RTP and RTCP ports for external BGM 1. 0000-9999 8104
(8105)
