4.4.5.28 System Call Routing - PGM 251
Selecting System Call Routing will display the System Call Routing data entry page. Enter a valid
Index range and click [Load] to enter Call Routing data. Click [Save] button after changing Value.
Figure 4.4.5.28-1 System Call Routing
System Call Routing establishes scenarios with criteria to route calls. Criteria include time 0f day,
day of week, Caller and Called numbers, etc. System Call Routing takes precedent over other
system based call routing. However, Station and CO Call Routing scenarios take precedence
over System Call Routing scenarios.
Table 4.4.5.28-1 System Call Routing Attributes
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Caller ID
This field defines the Caller Id for the
scenario.
Max. 23 Digits N/A
Called Num
This field defines the Called number for this
scenario.
Max. 23 Digits
Time condition (Start Day and
End Day, weeks, start time and
end time)
The time and day for activation of the
scenario can be defined.
YYYY-MM-DD
hhmm
(Must be 4 digits)
Destination (Type and Value)
This field defines the destination type and
value for call routing when the scenario
criteria are met.
STA
Station Group
SPD
PABX/
VSF/
VSF(#)/
Net Station/
Company room/
INT Page/
N/A
