4.4.4.10 NA ISDN Line Attributes - PGM 150
Selecting NA (North America) ISDN Line Attributes will display the NA ISDN Line Attributes data
input page. Enter a valid CO range and click [Load] to enter the NA ISDN Line Attributes data.
Use the check mark to indicate which attributes to modify; data for checked attributes is stored by
clicking [Save] button.
Enter CO Range
: eMG80: 1-74 / eMG800: 1-600 / UCP: 1-998
Figure 4.4.4.10-1 NA ISDN Line Attributes
To comply with the North American ISDN standards, certain attributes must be defined for the
system. These include Directory (telephone) Number and Service Profile Id (SPID) for the device.
Note that this programming is required only for “Country Code” 1, USA installations. Refer to
Table 4.4.4.10-1 for information on individual attributes.
Table 4.4.4.10-1 NA ISDN LINE ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Local Exchange Type
The type of ISDN determines several specifics of the
protocol and is required for proper operation.
NI 1/
NI 2/
5 ESS/
Nortel
NI 2
SPID Number
The Service Profile Identifier (SPID) is a number
assigned to a fully initializing ISDN terminal and
enables the Stored Program Control switching System
(SPCS) to identify the ISDN terminal at layer 3 of the
D-channel signaling protocol. The SPID is a free-
formatted numeric string composed of 9 to 20 numeric
{0-9} and International Alphabet (IA5) characters. The
20 digits
