Appendix C Database Details & Default
for Station Administration for eMG
The following Tables, divided based on the Program group and Program, provide the default
values assigned to all Admin entries. Prior to changing an entry during programming assure you
have an understanding of the PROGRAM and its purpose.
Table C-1 SYSTEM ID
BTN SUB-MENU DEFAULT REMARK
PGM: 100 -System ID
1
Country Code
1
Maximum 4 digits
2
Customer Site Name
Maximum 24 characters
3
My Area Code
Maximum 6 digits
4
Numbering Plan Type
1
Overall default Numbering Plan, the 1
st
station digit should
be 1 – 4.
2
The station number can be from 100~799.
3
Australia Default
4
New Zealand Default
5
Italy Default
6
Finland Default, Max Station Ports is 60.
Stations above Max ports will be displayed “***”.
7
Max Station Ports 70 Stations above Max ports will be
displayed “***”.
8
The station number can be from 100~ 999.
5
PRIFIX Usage
6
System ID reset
System reset
Table C-2 Numbering Plans
BTN SUB-MENU DEFAULT REMARK
PGM: 102 -System IP Address Plan
1
MPB Address
10.10.10.2
Public IP Address for H.323 calls
2
MPB Subnet mask
255.255.255.0
3
Router IP Address
10.10.10.1
Router IP Address for WAN access
4 System start IP address
10.10.10.10 Private start address for system to
module & terminal communications
5 System end IP address
10.10.10.254
Private end address for system to
module & terminal communications
6
System Subnet mask
255.255.255.0
7
Automatic IP Address Assignment
ON
8
Second System IP Address
0.0.0.0
Second Private IP Address for modules
9 Second System Net Mask
255.255.255.0 Second Private Sub-net Mask for
modules
10 Firewall IP Address
0.0.0.0 IP Address of firewall for external
network (WAN/IP) access
11
First Start Mac Address
00:00:00:00:00:00
First : Start MAC Address to register a
