iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
199
3.3.10.5 Network Feature Code Table PGM 325
PROCEDURE:
NET FEATURE CODE TBL
ENTER BIN NO (01-20)
1. Press the [PGM] button and dial 325 and enter the bin
number (Ex.01).
01 NET FEATURE CODE TBL
PRESS FLEX KEY (1-2)
Use the dial-pad to enter the bin no.
Press the Flex button 1~2 for the desired setting, refer to
Table 3.3.10.5-1.
Use the dial-pad to enter the required data, refer to Table
3.3.10.5-1.
Press the
[Save]
button to store the new data.
Table 3.3.10.5-1 NETWORK FEATURE CODE TABLE (PGM 325)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
01 NET FEATURE CODE
...............
Networking Feature Code
programming for Networking paging
call.
16 digits
2
01 NET DEST
NONE (1-6)
Select network feature type (1-6)
and dial associated number.
INT PAGE ZONE (eMG80:01-
35/eMG800:1-100)
EXT PAGE ZONE : (1-1)
ALL CALL PAGE ZONE : (1-3 :
1(INT), 2(EXT), 3(ALL))
DOOR OPEN : 1~2
Conference Room (1-9)
Call park (eMG80:01-
19/eMG800:1-200)
1 : INT PAGE
2 : EXT PAGE
3 : ALL CALL
PAGE
4: DOOR OPEN
5:Conference
Room (1-9)
6:Call park (01-
19)
N/A
