iPECS UCP - H.323 Incoming Route Table

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
524
4.4.11.3 H.323 Incoming Route table -PGM 328
Selecting H.323 Incoming Route table will display the data entry page. Click [Save] button after
changing Value.
Enter CO Group number
: eMG80 : 1-20 / eMG800: 1-200 / UCP: 1-200
Figure 4.4.11.3-1 H.323 Incoming Route table
To get the direct H.323, the From IP-Address and ‘incoming CO Group number’ to be routed
should be assigned.
Table 4.4.11.3-1 H.323 Incoming Route table
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Calling IP Address
IP address associated with H.323 incoming calls.
255.255.255.255 is used when external call cones from
unknown IP Address which is not listed in this table entry.
0.0.0.0
CO Group
CO group number associated with H.323 incoming calls.
eMG80:1~20
eMG800:1~200
UCP:1~200
0
