3.3.17 VIRTUAL DIP-SWITCH — PGM 453
The Virtual Dip Switch is employed to change from in-band to SMDI for External Voice Mail
communications and manually poll each IP KTS device.
PROCEDURE:
VIRTUAL DIP SWITCH
PRESS FLEX KEY (1-6)
1. Press the [PGM] button and dial 453.
To enable trace, press desired Flex button 1~6. The Flex
button LEDs indicates Dip switch setting, On/Off. Press the
desired Flex button to toggle setting,
LED On: enabled
LED Off: disabled
To enable call trace, press the
[Save]
button.
Table 3.3.17-1 VIRTUAL DIP-SWITCH (PGM 453)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
VIRTUAL DIP SWITCH
DEVICE POLLING: (ON)
‘Device polling’. If enabled (On), the
system will check each registered
device, Gateway/Board and iPECS
Phone to determine if the device is
alive or not.
0: OFF
1: ON
ON
2
VIRTUAL DIP SWITCH
SMDI SETTING: (OFF)
SMDI setting is enabled for output. 0: OFF
1: ON
OFF
3
VIRTUAL DIP SWITCH
MULTICAST LED: (OFF)
If this value is set, the LED
commands from MPB will be sent to
Gateway/boards and terminals in
the multi-cast mode.
0: OFF
1: ON
OFF
4
VIRTUAL DIP SWITCH
AUTO NEGO: (MANUAL)
This field enables negotiation of
speed between the LAN switch port
and the system.
0: AUTO
1: MANUAL
MANUAL
5
VIRTUAL DIP SWITCH
FULL-HALF: (FULL)
The duplex mode of LAN
connections can be set according to
this field.
0: FULL
1: HALF
FULL
6
VIRTUAL DIP SWITCH
10-100 TX: (100)
The speed of the Ethernet interface
is established based on this field,
10 Base T or 10/ 100 Base T.
0: 100
1: 10
100
