destination port -> dst port #number
IP filter: both source and destination host IP -> host #IP_ADDR, source host IP -> src host
#IP_ADDR, destination host IP -> dst host #IP_ADDR
# Example
UDP and Port 5588 and Source IP address 10.1.1.100: udp and port 5588 and src host
10.1.1.100
A user can start and stop logging and download trace log result. The log file will be replaced
when new logging is started.
Trace Log via web
1. Set 'Trace Attribute' to 'COM1(UART1)' from 'Set Trace Direction' menu.
2. Set 'Board Trace', 'Device Trace' and 'Virtual Trace Dip Switch(P452)' menu.
3. Click [Start] button.
4.5.17 TDM Gain Control
Control voice gain of TDM device for each direction. For more information to change Value, it is
recommended that you ask your dealer or an authorized Ericsson-LG Enterprise representative.
We can’t guarantee the damage according to changing Value arbitrarily.
Figure 4.5.17-1 TDM Main Page
