iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
581
4.5.1.2.2 iPECS eMG/UCP Upgrade Process
The following shows the order in which the upgrade process proceeds and firmware files for
iPECS and modules. Note the xxxx in the ROM file names indicates the version number of the file.
iPECS Software Full Upgrade Sequence
1. Upload MPB/UCP application image.
MPB/UCP Upgrade Process
iPECS UCP UCP application image
(Example, S-UCP-Rls1601-2.1.1-app.rom
iPECS eMG eMG 80/800 MPB application image
(Example,
eMG80: S-eMG80MPB-Rls1512-2.1.1-App
eMG800: S-eMG800MPB-Rls1512-2.1.1-App)
2. Restart MPB/UCP.
Note:
If the new system database is not compatible with existing system database, it will be necessary
to initialize the system database. This can be done manually using the Initialize Dip Switch
located on the UCP/MPB module or via the Initialization Web page.
Upgrade of the UCP/MPB includes HTML files; a separate upload of the HTML files is not
required. HTML files can be separately upgraded under the File System
1. Upload Appliance application image to MPB
Appliances Upgrade Process
LIP 8012/8024/8040E application image:
GS98Pxxxx.rom (xxxx indicates the version)
LIP 8002E application image:
GS99Pxxxx.rom (xxxx indicates the version)
2. Select target appliances & Upgrade application image and click [Upgrade].
3. Wait until upgrade process completes.
4. Automatically restart when upgrade completes successfully.
1. Access to VSF Prompt Upgrade page.
Upgrade of Voice Prompt for eMG
2. Select First/Second/Third for multiple language voice prompt.
3. Upload the proper prompt file.
??96Wxxxx.rom (?? Is nation, i.e. GS, DM, KR, etc. ; xxxx indicates the version)
1. Access to MPB.
Upgrade of Voice Prompt to VMIU for eMG
2. Select First/Second/Third for multiple language of voice prompt.
3. Upload the proper prompt file to VMIU.
??96Wxxxx.rom (?? Is nation, i.e. GS, DM, KR, etc. ; xxxx indicates the version)
