iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
197
3.3.10.4 NET Numbering Plan Table – PGM 324
PROCEDURE:
NET NUM PLAN TABLE
ENTER BIN NO (000-251)
1. Press the [PGM] button and dial 324 and enter bin
number (Ex.001).
001 NET NUM PLAN TBL
PRESS FLEX KEY (01 – 16)
Use the dial-pad to enter the 3-digit Table index (bin)
number, 000 ~ 251.
Press the Flex button, 1~16 for the desired setting, refer to
Table 3.3.10.4-1.
Use the dial-pad to enter the required data, refer to Table
Press the
button to store the new data.
Table 3.3.10.4-1 NETWORK NUMBERING PLAN (PGM 324)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
001 SYSTEM USAGE
(0:NET/1:PSTN) : NET
Select system usage 0: NET
1: PSTN
NET
2
001 NUM PLAN CODE
. . . . . . . . . . . .. .
‘*’ means any digits can be
inserted between 0 ~ 9.
The digits followed by ‘#’ are an
16 digits
3
001 NUM PLAN CO GRP
(00 - 24) : . .
‘00’ means an internal net station
number
00-24 ..
4
001 CPN INFORMATION
PRESS FLEX KY (1-4)
Flex 1: ISDN CPN
INFORMATION
Flex 2: ( Flex button 1- 4 )
1: 00 CPN INFORMATION 01
2: 00 CPN INFORMATION 02
3: 00 CPN INFORMATION 03
16 digits
5
001 ALT SPD BIN
(2000-4999) : . . . .
Alternative Dial Number (System
SPD Bin) when the networking
path has a fatal problem.
eMG80:2000~4999
eMG800:2000~9999
6
DEST SYSTEM IP ADDR
0 . 0 . 0 . 0
IP Address of destination MPB
system only when iPECS eMG is
configured for Voice Networking.
0.0.0.0
7
DEST SYSTEM PORT NO
(0000-9999) : 5588
Port Number of destination
system for Networking.
0000-9999 5588
8
001 DIGIT REPEAT
(0:NO/1:YES): NO
When the number plan code (Flex
2) is for PSTN call or transit-call,
this number code can be
enveloped in SETUP message or
not whether if this field is set or
0: NO
1: YES
NO
