iPECS UCP - 2.20.2 Call Transfer, Station

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
61
Use the dial-pad to enter the type and value for the desired
Idle Line selection, refer to Table 3.3.3.10-1.
Press the [Save] button to store the data entry.
Table 3.3.3.10-1 IDLE LINE SELECTION TYPE & VALUE (PGM 121)
TYPE
VALUE
DESCRIPTION
1
Flex button
Flex button, activates Flex Number as if dialed.
2
CO line
CO/IP path seizes CO line.
3
CO group
CO/IP Group seizes CO line from the CO/IP Group.
4
Station
Station, calls the assigned station
5
Hunt Group
Call to Hunt Group
6
Station Speed
Call to Station Speed
7
System Speed
Call to System Speed
3.3.3.11 Station IP Attributes – PGM 122
Stations are allowed access to the systems H.323 VoIP resources based on the Station IP
Attributes. Refer to Table 3.3.3.11-1 for a description of the attributes and the inputs available.
PROCEDURE:
STATION IP ATTRIBUTE
ENTER STA RANGE
1. Press the [PGM] button and dial 122.
100-110 STA IP ATT
PRESS FLEX KEY (1)
Use the dial-pad to enter a station range (Ex. 100~110). For
a single station, enter the same number twice.
Press the desired Flex button; refer to Table 3.3.3.11-1.
Use the dial-pad to enter desired data for the Station IP
Attribute, refer to Table 3.3.3.11-1.
Press the
[Save]
button to store the data entry.
Table 3.3.3.11-1 STATION IP ATTRIBUTES (PGM 122)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
100-110 DTR IP CALL
(1:EN/0:DIS) : ENABLE
Enables station to access an IP
channel directly by dialing the IP
Group access code to place
H.323 or SIP VoIP calls.
0: Disable
1: Enable
Enable
