4.4.4.4 ISDN Attributes - PGM 143
Selecting ISDN Attributes will display the ISDN Attributes data input page. Enter a valid CO range
and click [Load] button to enter the ISDN Attributes data. Use the check mark to indicate which
attributes to modify; data for checked attributes is stored by clicking [Save] button.
Enter CO Range
: eMG80: 1-74 / eMG800: 1-600 / UCP: 1-998
Figure 4.4.4.4-1 ISDN Attributes
PGM 143 assigns attributes associated with ISDN lines in the entered range.
Table 4.4.4.4-1 ISDN ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
TEI Type
The TEI (Terminal Endpoint Identifier) is a unique
identifier for each device attached to the ISDN line.
When the system shares an ISDN connection with
other devices, the TEI should be automatic to assure
no conflict with the other attached devices.
Otherwise, the Fixed identifier option should be
employed.
Fixed/
Automatic
Automatic
ISDN – SS CD/CR(CFU)
Permits a user to access to ISDN Supplementary Call
Deflection Service. (Except USA version).
No Service/
Call Deflection/
Call Rerouting
No Service
Advice of Charge
When assigned, the system will analyze the Advice of
Charge information in the Facility Message according
to the ETSI specifications with appropriate regional
protocol support.
No AOC/
Italy & Spain/
Finland/
Australia/
Belgium/
ETSI STD
No Service
