iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
164
3.3.8.2 CLIP/COLP Table – PGM 201
Normally, the system will send the primary Directory Number of the ISDN Line in the ISDN call
SETUP and CONNECT messages to identify the caller (CLIP) or the answering (COLP) party
respectively. Under certain circumstances, it may be desirable to provide a secondary or DID
number for the ISDN Line. In these cases, the CLIP/COLP Table may be used to define the digits
sent. The number sent is selected based on the index assigned for the ISDN Line under CO/IP
Attributes III (PGM 143).
For the CLIP/COLP Table entry, the CLI Station Number (PGM 114) is sent in place of the station
number. For all other CLIP/COLP Table entries, the station number is sent as a suffix to the
number in the Table. Note that this number is sent only if CLIR and COLR are disabled under the
CLIR Service and COLR Service assignments in the Station ISDN Attributes (PGM 114).
PROCEDURE:
CLIP/COLP TABLE ENTRY
ENTER BIN NO ( 00 –4 9 )
1. Press the [PGM] button and dial 201 and enter the bin
number (Ex.00).
CLIP/COLP TABLE 00
……….
Use the dial pad to enter the desired Bin number (00-49)
Use the dial pad to enter the desired CLIP/COLP data,
maximum 10 digits.
Press the [Save] button to store the CLIP/COLP data entry.
