iPECS UCP - Network Supplementary Attribute

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
195
3.3.10.2 Network Supplementary Attribute – PGM 321
PROCEDURE:
NET SUPPLEMENTARY ATTR
PRESS FLEX KEY (1-9)
1. Press the [PGM] button and dial 321.
Press Flex button 1~9 for the desired setting, refer to Table
3.3.10.2-1.
Use the dial-pad to enter the required data, refer to Table
3.3.10.2-1.
Press the [Save] button to store the new data.
Table 3.3.10.2-1 NETWORK SUPPLEMENTARY ATTRIBUTE (PGM 321)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
NET TRANSFER MODE
(1:RERT/0:JOIN) :REROUT
Select type for Transfer and Call
forward – Rerouting or Join
1: RERT
0: JOIN
REROUT
2
TCP PORT FOR BLF
(9500-9999) :9500
TCP port for sending BLF message
to BLF Manager
0000-9999 9500
3
UDP PORT FOR BLF
(9500-9999) :9501
UDP port for sending BLF message
to BLF Manager
0000-9999 9501
4
BLF MANAGER IP
0 . 0 . 0 . 0
IP Address of BLF Server used only
when iPECS is configured with LDK
systems for Voice Networking
0.0.0.0
5
DURATION OF BLF STS
(01-99) 100 mm sec : 10
Duration of BLF status message
sending to BLF Server.
01-99
(msec)
10
6
MULTI CAST IP
0 . 0 . 0 . 0
IP address of Multicast for BLF
service.
0.0.0.0
7
NET TRANS FAULT RCL TMR
(001-300)sec : 010
Network transfer fault recall timer to
be used when no responses from
other systems.
001-300
(seconds)
10
8
VOIP CALL REROUTE CO GR
(00-20) : 00
SIP outgoing call is rerouted via
alternative backup CO line when
call is failed or there is no answer
during 3 seconds.
eMG80:1-20
eMG800:1~200
00
9
BLF SERVICE USAGE
(1:ON/:OFF) :ON
Enable/disable for BLF manager
function.
0: OFF
1: ON
ON
