iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
75
3.3.5 CO LINE DATA – PGM 140 to 151
3.3.5.1 CO Service Type – PGM 140
Each CO Line is assigned a type, Normal or DID. Normal CO Lines can be employed for DISA
Service PGM 146. DID lines are for incoming only operation and provide call routing based on
signaling from the carrier, refer to section 3.3.5.4 DID Service Attributes - PGM 145.
PROCEDURE:
COL SERVICE ATT
ENTER COL RANGE
1. Press the [PGM] button and dial 140 and enter the range
(Ex. 0102).
01-02 SVC TYPE
PRESS FLEX KEY (1-1)
2. Press the desired Flex button.
01-02 SVC TYPE (1-4)
NORMAL CO (1)
Use the dial pad to enter a CO Line range. For a single CO
Line, enter the same number twice.
Use the dial pad to enter the desired service type:
1. Normal CO line
2. DID line
3. TIE line
4. Unused
Press the [Save] button to store the data entry.
3.3.5.2 CO/IP Attributes I ~ III - PGM 141~143
CO/IP Attributes define various characteristics of the CO lines and IP facilities under control of the
system. Most require a dial pad input of 1 or 0 to set the characteristic, refer to Table 3.3.5.2-1 to
Table 3.3.5.2-3. Specific descriptions for Class-of-Service and CO line Call Metering tones are
provided in Table 3.3.5.2-4 and Table 3.3.5.2-5 respectively.
PROCEDURE:
CO/IP ATTRIBUTE 1
ENTER COL RANGE
1. Press the [PGM] button and dial:
141 for CO/IP Attributes I
142 for CO/IP Attributes II
143 for CO/IP Attributes III.
01-02 CO/IP ATT 1
PRESS FLEX KEY (01-24)
Use the dial-pad to enter a CO/IP line range. For a single
CO/IP Line, enter the same number twice.
Press the desired Flex button; refer to Table 3.3.5.2-1 to
