PROCEDURE:
Use the dial-pad to enter desired data for the Attribute, refer
to Table 3.3.5.2-1 through Table 3.3.5.2-5.
Press the
[Save]
button to store the data entry.
Table 3.3.5.2-1 CO/IP ATTRIBUTES I (PGM 141)
BTN ATTRIBUTE/DISPLAY DESCRIPTION DEFAULT
1
01-02 CO/IP GROUP
GRP NO (01-20) : 01
Each CO Line is assigned to a group;
grouping should be based on the Line type
and COS.
01
2
01-02 CO LINE COS
COS (1–5) : 1
Each CO Line is assigned a Class-of-Service
which will interact with the Station COS, refer
to section 3.3.5.2.
CO COS 1: Station COS applies
CO COS 2: Exception Table A governs
CO COS 3: Exception Table B governs
CO COS 4: Restricts LD calls and Exception
Table C
CO COS 5: Overrides Station COS 2~6 with
no restrictions.
1
3
01-02 CO START SIGNAL
(1:GND/0:LOOP) : LOOP
The system can recognize a loop closure or a
ground as the “connect” (start) signal on an
analogue CO Line.
LOOP
4
01-02 CO LINE TYPE
(1:PBX/0:CO) : CO
Each CO Line can be assigned as connected
to a CO Line or a PBX/CTX Line.
CO
5
01-02 CO LINE SIGNAL
(1:DTMF/0:PULSE):DTMF
Each analogue CO Line can be assigned to
send either DTMF or Pulses for dialed digits
to the PSTN.
DTMF
6
01-02 UNSED
7
01-02 UNIVERSAL ANS
(1:ON/0:OFF) : OFF
Universal Night Answer (UNA) allows any
station to answer a call on the CO Line by
dialing the UNA code.
OFF
8
01-02 CO/IP GRP AUTH
(1:ON/0:OFF) : OFF
Each CO/IP Group can be assigned to require
the user enter an Authorization Code for
access.
OFF
9
01-02 DATA STATION NO
FAX : ….
Each CO/IP line can be assigned to recognize
a FAX call when a specified station answers.
….
10
01-02 TENANCY GROUP
(00-15) : 00
Only stations in the assigned Tenancy group
are permitted access to the defined CO Line.
00
