iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
77
Table 3.3.5.2-1 CO/IP ATTRIBUTES I (PGM 141)
BTN ATTRIBUTE/DISPLAY DESCRIPTION DEFAULT
11
01-02 CO VOIP MODE
VOIP MODE(1-6) : COMMON
The VOIB channels can support iPECS,
H.323 or SIP protocols. This field defines the
protocol for the VoIP channel(s).
1: COMMON
2:H.323 ONLY
3: SIP ONLY
4:RTP RLY
5:H.323/RTP RLY
COMMON
12
01-02 PROCTOR ON/OFF
(1:ON/0:OFF) : OFF
Each analogue CO line can be assigned to
send the station number as DTMF digits for
Proctor service.
OFF
13
01-02 WAIT IF VSF BUSY
(1:ON/0:OFF) : ON
When a DID/DISA call assigned to receive a
VMIU/VMIB announcement arrives and all
channels are busy, the call may wait with Ring
back until a channel is available (ON) or route
to the DID/DISA Destination - PGM 167.
ON
14
01-02 UNUSED
15
01-02 UNUSED
16
01-02 RING TONE
(00-12, 0:N/A) : 00
Ring Tone can be programmable by CO-line
base admin.
00
17
01-02 UNUSED
18
01-02 GAIN TABLE
(1-3) : 1
TDM gain table can be programmed. 1
19
01-02 TONE TBL
(1-5) : 1
Tone table can be programmed. 1
20
01-02 DGT CONV. TBL
(01-15) : 01
Select digit conversion table. 01
21
01-02 PREPAID CALL
(1:ON/0:OFF) : OFF
Enables Pre-paid Call feature. OFF
To Next Page
