iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
78
Table 3.3.5.2-1 CO/IP ATTRIBUTES I (PGM 141)
BTN ATTRIBUTE/DISPLAY DESCRIPTION DEFAULT
22
01-02 PREPAID MONEY
0 (USED:0)
An amount can be associated with the station
as prepayment for outgoing calls. The
assigned “Pre-paid Money” is reduced by the
calculated call cost (Call Metering or
cost/minute). This parameter displays the
remaining funds for outgoing calls. Prepaid
Money is often used in small hospitality
businesses.
The “Used Pre-paid Money” displays the
money that has been used.
23
01-02 LDT ZONE
(001-100) : 001
If the LDT Zone Number of a station/co line is
equal to this value, this LDT table is available
001
24
ADDED CO/IP ATTRIBUTE 1
PRESS FLEX KEY (1-2)
24-1
01-02 ICLID USAGE
(0-2) : CLI
An incoming call can be routed to the
destination based on Calling Name.
Disable - ICLID feature is disabled
CLI - ICLID feature is operated with CLI
Name - ICLID feature is operated with Name
CLI
24-2
01-02 EMERGENCY PBX C
(0-4) : DISABLE
System can insert PBX code automatically if
pre-configured when a user make an
Disable
Table 3.3.5.2-2 CO/IP ATTRIBUTES II (PGM 142)
BTN ATTRIBUTE/DISPLAY DESCRIPTION DEFAULT
1
01-02 CO NAME DISPLAY
(1:ON/0:OFF) : OFF
The IP Phone display can indicate the CO
Line/IP channel number or a twelve (12)-
character name, if assigned.
OFF
2
01-02 CO NAME ASSIGN
…………
Each CO Line and the IP group can be
assigned a twelve (12) character name for
display purposes, see Table 3.1.2-1 for
character entry sequence.
3
01-02 METERING UNIT
00:NONE (0-6)
Selects the call-metering signal from the
PSTN to indicate call cost, refer to Table
00
4
01-02 LINE DROP(CPT)
(1:ON/0:OFF) : OFF
Each CO Line can be programmed to
disconnect if an error tone is detected.
OFF
5
01-02 DISA ACCT CODE
(1:ON/0:OFF) : ON
With DISA ACCT CODE “ON”, users will be
required to enter an Authorization code. Enter
codes in Authorization Codes Table - PGM
ON
