3.3.4 BOARD DATA – PGM 130 to 132
3.3.4.1 H.323 VoIP Attributes – PGM 130
The VOIP channels are used for Distributed Networking, access to SIP or H.323 networks and for
remote iPECS devices. When the standard H.323 VoIP protocol is employed for an external VoIP
call, several attributes of these channels can be assigned. The H.323 call set-up mode and
tunneling (H.245 Encapsulation) can be established.
Also for H.323 support, a RAS (Registration, Admissions and Status) channel can be defined.
The RAS channel IP addresses (uni-cast and multi-cast) as well as the IP port Numbering Plan
and other H.323 set-up characteristics are defined.
This PGM also allows setting the IP TOS bit for Diffserv, a commonly recognized packet
prioritization protocol. Higher priority packets are given priority in the Router or Layer 3 Switch
queue. However, they are the first to be discarded in the event of long queue delays, which may
cause excess packet loss and poor voice quality.
Refer to Table 3.3.4.1-1 for a description of the features and the input required.
PROCEDURE:
H323 VOIP ATTRIBUTE
ENTER SEQ NO(001-300)
1. Press the [PGM] button and dial 130. eMG800 range is
0001-2890.
001 H323 VOIP ATTR
PRESS FLEX KEY (01-24)
Use the dial pad to enter the VoIP board sequence number.
Press the desired Flex button; refer to Table 3.3.4.1-1.
Use the dial pad to enter the desired data, refer to Table
3.3.4.1-1.
Press the
[Save]
button to store the data entry.
Table 3.3.4.1-1 H.323 VOIP ATTRIBUTES (PGM 130)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
H.323 SETUP MODE
(1:FAST/0:NORM): FAST
H.323 IP calls can be set-up
using the H.323 normal or Fast
Start mode.
0: Fast
1: Norm
Fast
2
H.323 TUNNEL MODE
(1:ON/0:OFF) : ON
H.323 IP calls can be set-up
using the H.245 encapsulation
(Tunneling).
0: OFF
1: ON
ON
3
H.323 DTMF PATH
(0:IN/1:OUT/2:2833): 0
During a connection, DTMF Digits
can be sent in-band or out of
band (H.245).
0: In band
1: Out band
2: 2833
0
4
DIFFSERV PRETAG
TAG (00-63) : 04
Diffserv pre-tagging for Voice
packet. Note high values may
cause high packet discard levels.
0~63 4
