iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
171
3.3.9 TABLES DATA – PGM 220 to 235
3.3.9.1 LCR Assignment Tables - PGM 220 to 223
The LCR Tables provide a mechanism to define the database, which will route outgoing calls,
particularly long distance, using the most cost effective route. User dialed digits are compared to
table entries and modified appropriately based on time of day, day of week, and assigned routes.
There are four LCR Tables, LCR Control Attributes, LCR Leading Digit Table, LCR Digit
Modification Table, and LCR Initialization Table.
3.3.9.1.1 LCR Control Attributes - PGM 220
The LCR Control Attributes, among others items, allows access to the LCR Access Mode
assignments. The LCR Access Modes define the user operations that will access the LCR feature.
The LCR Access Modes are:
Loop (user dials ‛9’ or CO/IP Group code (8xx) or presses a Loop button)
Loop and Internal (user dials digits without a CO/IP Access Code prefix)
Loop and Direct CO Line (user dialed CO Line Access Code, or presses {CO} button).
Loop, Direct CO Line, and Internal
Loop, Direct CO Line, Internal and Direct
In addition, days of the week are grouped into zones (Day Zones) and the time of day can be set
into three groups (Time Zones). Table 3.3.9.1.1-1 provides general descriptive information and
input ranges.
− PROCEDURE:
LCR CONTROL ATTRIBUTES
PRESS FLEX KEY (1-5)
1. Press the [PGM] button and dial 220.
Press Flex button 1~5, refer to Table 3.3.9.1.1-1.
For LCR Access Mode and Time Zones, use the dial-pad to
enter desired data and proceed to step 5). Refer to Table
3.3.9.1.1-1 for input ranges. For Day Zones press the Flex
button 1~7 to select the day of week, Monday: Flex button 1
to Sunday: Flex button 7.
For Day Zones, after selecting the desired day of week Flex
button, use the dial pad to enter the desired zone, 1~3.
Press the
button to store the data entry.
To Next Page
