iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
204
Table 3.3.11.4-1 FAIL-OVER ATTRIBUTES (PGM 333)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
2
INIT FoPSTN TABLE
PRESS [Save] KEY
This field is used to initialize the FO table.
3
FoPSTN ATTRIBUTES
ENTER BIN NO(000-199)
3-1
FoPSTN 001 NUM PLAN
xxxxxxxx
Station numbers associated with the
remote system. A range can be indicated
by using “*” to indicate the range.
Max 8 digits
3-2
FoPSTN 001 CO GROUP
GRP NO (00-21) : 01
This field defines the CO Group of the
local system that will be used to place
calls to the stations entered in the FO
Numbering Plan, should WAN failure
eMG80:1~20
eMG800:1~200
3-3
FoPSTN 001 TEL NUMBER
xxxxxxxxxxxxxxxxxxx
This field defines the telephone number
the system should dial to place a call to
the stations entered in the FO Numbering
Plan, should Wan failure occur. An “*”
may be entered as a wild-card to indicate
insertion of the dialed station number.
3.3.11.5 TNET LM External Contact Attributes – PGM 334
Each LM incorporates relay contacts, which can be employed as a Door Lock Release. The
contact activates a 3
rd
party Door Lock Release mechanism activated by dialing the Door Unlock
code at a local station. Note assigning other functions to the contact may cause unexpected
operation.
PROCEDURE:
TNET LM EXT CONTACT
ENTER BIN NO (01-15)
1. Press the [PGM] button and dial 334.
The range is : eMG80 : 1-15 / eMG800: 1-32
LM(01) EXT CONTACT
PRESS FLEX_KEY (1-4)
Select LM number
Select Flex button 1~4 for the desired External Control
Use the dial-pad to enter desired data.
1. LBC + station number, (ex. 150)
2. Door Lock Release
3. External Page 1 access
4. External Page 2 access
Press the [Save] button to store the External Contact data
