iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
167
3.3.8.5 ICLID Ring Assignment – PGM 204
If the Incoming Caller ID matches an entry in the ICLID Route Table, the index from the Table is
used to determine the call routing from the ICLID Ring Assignment Table. Separate ring
assignments are made for Day, Night, and Timed Ring mode for each index, 001 to 250, in this
table. When assigned to ring to a VSF announcement, the call can be automatically dropped after
the announcement by entering ‘#’ after the announcement number.
When CO Lines are programmed to Ring an external AA/VM, VSF or Feature Server Group as
an Automated Attendant, the Ring signal can be on an immediate or delayed basis allowing other
stations/groups to be assigned Ring and answer prior to signaling the AA. The delay is defined in
seconds from 00 to 30.
PROCEDURE:
ICLID RING ASN TBL ATT
ENTER BIN NO (001-250)
1. Press the [PGM] button and dial 204 and enter the bin
number (Ex.001).
PRESS KEY
DAY NIGHT TIMED-R
Use the dial pad to enter the Index or Bin number (001 –
250).
Press the desired Flex button:
Button 1: Day Ring
Button 2: Night Ring
Button 3: Timed Ring
Use the dial pad to select the destination type:
Dial 1: Station
Dial 2: Hunt Group
Dial 3: VSF Announcement
Dial 4: AA Ring Time
Use the dial pad to enter a value for the selected destination
type.
Press the [Save] button to store the data entry.
