3.3.11.2 TNET CM Attributes – PGM 331
Each LM (Local MPB), which is part of a Central Control Network, must be defined with the IP
Address of the CM (Central MPB) as well as the LM configuration data that will be sent to the CM
at the time the LM registers with the CM. The port counts define the ports, which are allocated in
the CM database for use by devices registered to the LM. The number of ports defined in the
database of each LM must be equal or less than the ports defined in the CM for the LM, see PGM
332, in order to register properly.
PROCEDURE:
TNET CM ATTRIBUTES
PRESS FLEX KEY (1 – 10 )
1. Press the [PGM] button and dial 331.
Press the Flex button, 1~6 for the desired setting, refer to
Table 3.3.11.2-1.
Use the dial-pad to enter the required data, refer to Table
3.3.11.2-1.
Press the [Save] button to store the new data.
Table 3.3.11.2-1 TNET CM ATTRIBUTES (PGM 331)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
CM REGISTER REQ
(1:ON/0:OFF) : ON
This field informs the LM to attempt
registration with the CM. This field must
be set to ON for proper registration.
0: OFF
1: ON
OFF
2
CM SERVER TYPE
0:LIK / 1:CM : LIK(0)
This field defines Central Call Manager
type. The LIK is eMG/UCP even though
the display is LIK.
0:LIK
1: CM
LIK
3
CM1 IP ADDRESS
0 .0 .0 .0
This field defines the IP address of the
CM1 that will be used by the LM.
IPv4
address
4
CM2 IP ADDRESS
0 .0 .0 .0
This field defines the IP address of the
CM2 that will be used by the LM.
IPv4
address
5
CM1 MAC ADDRESS
000000000000
This field defines the MAC address of
the CM1 that will be used by the LM.
6
CM2 MAC ADDRESS
000000000000
This field defines the MAC address of
the CM2 that will be used by the LM.
7
CM IPKTS PORT
(0001 - 9999) :5588
In the TNET environment, the IP KTS
protocol signaling UDP port is defined.
At present this field is not used, do not
change this port number.
0000-9999 5588
