2. SYSTEM & ADMIN INFORMATION
2.1 System capacities for eMG and UCP
iPECS eMG is available in several hardware configurations based on the Main board of the KSU.
Upon initialization, the software will structure a database for the maximum possible station and
CO/IP Line configurations. Thus, the software port count capacities will differ from the hardware
count however, the hardware limitations always apply. The total System ports supported by the
software include the Station ports, CO/IP Line ports and ports for various options including the
integrated AA/VM, Miscellaneous ports, etc. Other than the Station and CO/IP Line ports, the
hardware and software capacities are the same. The capacities relative to the software are
provided in the table below.
Table 2.1-1 eMG80 Software Capacities
Item Capacity
CO/Trunk lines Max. 74
Stations
Max. 140
Attendants 4
LAN port
2 (1 each, KSU and VVMU)
Modem Channel
1 (MODU)
Serial Port(RS-232C)
1
USB(2.0) Host port 1
Alarm/Doorbell input
2 (1 per KSU)
External Control Relays 2 (1 per KSU)
Music Source Inputs
1 Internal: select one of 13 melodies
1 External source input
5 SLT ports
3 VSF announcements
Power Fail Circuit
Max. 6 (1 per KSU, EKSU, CH204, CH408, CS416)
VSF Device 1: Built-in AA/VM
w/MEMU
w/MEMU2
VSF Device 2 (VVMU)
8 channels(2 Chan. by default, 1 Channel by license), 1 hour
15 hours(no license needed)
60 hours(no license needed)
8 channels (by license) & 15 hours(by license), 1 hour(by default)
Conference channels 148 channels/13 party per group
WTIB
1
DECT Phones 48
Built-in VoIP channels
8 (2 channels by default, 6 channels by license)
VVMU VoIP channels 8 (by license)
IP Stations and SIP Trunks
48 port (32 Stations+16 SIP Trunks)
External Page 1 port
Internal Page
35 zones
System Speed Dial 3000 numbers, 25 digits each
