3.3.6.16 Break/Make Ratio – PGM 176
For Pulse dial CO Lines, the system supports 10pps and the percent break/make ratios of 66/33
or 60/40.
PROCEDURE:
BREAK/MAKE RATIO
(1:66/33 / 0: 60/40): 60/40
1. Press the [PGM] button and dial 176.
Dial the digit (1 or 0) for the desired Break/Make ratio:
1: 66/33
0: 60/40
To save Break/Make ratio data, press the
[Save]
button.
3.3.6.17 SMDR Attributes – PGM 177
Station Message Detail Recording (SMDR) is an ASCII output of details on both incoming and
outgoing calls. Various SMDR attributes can be assigned including; output records for all calls or
LD only, call cost per pulse when using call metering, etc. Refer to Table 3.3.6.17-1 for a
description of each Attribute, LCD displays and the data entries required.
PROCEDURE:
SMDR ATTRIBUTES
PRESS FLEX KEY (01-24)
1. Press the [PGM] button and dial 177.
Press the desired Flex button; refer to Table 3.3.6.17-1.
Use the dial-pad to enter the desired data, refer to Table
3.3.6.17-1.
To save SMDR Attribute data, press the
[Save]
button.
Table 3.3.6.17-1 SMDR ATTRIBUTES (PGM 177)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
SMDR SAVE
(1:ON/0:OFF) : OFF
The system can store all outgoing calls
(ON) or only calls that exceed the SMDR
Timer (OFF).
The later allows PSTN call set-up times
to be removed from the recorded call
time. For SMDR Timer settings refer to
button 12 below.
0: OFF
1: ON
OFF
2
SMDR PRINT
(1 : ON/ 0: OFF) : ON
The system can output SMDR records
automatically as they occur (real-time) or
only when requested. When this attribute
is ON, SMDR output is automatic at call
completion.
0: OFF
1: ON
ON
